Built for demanding industrial environments, the HD Elite CNC Plasmatable is designed for heavy-duty, continuous-use applications. The system supports multiple torches and oxy-fuel cutting, making it well suited for large-scale fabrication and industrial production.

With a heavy-duty welded frame, high-speed motion system, precision bearing rails, automated nesting, and advanced torch-height control, the HD Elite is engineered for productivity, accuracy, and long-term industrial use.

Specifications

• Clearance Under Gantry: 14"
• Table Capacity: 8" standard
• Rapid Travel: 1,000 IPM
• Positioning Accuracy: 0.002"
• Repeatability: 0.003"

Controller

The HD Elite is equipped with an industrial control system featuring:

• FlashCut All-In-One CAD/CAM/CNC
• Eckelmann Package ProNest® CAD/CAM software
• Eckelmann Group Controller
• Windows Operating System

Features

• Precise plate alignment capabilities
• 750W AC servo motors
• High-precision Nidec Shimpo planetary gearboxes
• Sub 3-inch arc-minute accuracy
• Stingray Digital Torch Height Control (DTHC)
• Helical rack and pinion gears
• Industrial motor wiring
• Rapid speed of 1,800 IPM
• Industrial gantry with 14-inch clearance
• Milled precision bearing rails
• TrueShape AUTO Nesting
• Previous-cut THC turn-off to prevent unwanted diving
• Automatic lead-in on restart
• Motor current sensing
• Cut completion time progress meter
• Pneumatically controlled water level
• 10-inch water depth
• Removable slat trays
• 6-inch slats and 5-inch oversized cut area
• 33-inch table height
• Collision detection
• Ohmic sensing
• Magnetic torch / breakaway torch
• Industrial bearings
• Fully welded frame with adjustable leveling feet
• Ball screw Z-axis
• 22-inch operation screen

---

Accessories

The HD Elite can be configured with a range of accessories:

• Pneumatic Air Scribe
• Computer Stand
• Plate Marker
• OXY with High/Low Preheat
• Rotary
• Dual Tank System
• Laser Pointer
• Hand Pendant System
• Regulator & Hose Kit — 2 options
• Air Booster
• Gantry-Mounted Controller and Computer
• Maintenance Plans
• Tsunami Dryer Systems

---

Plasma Cutter Options

The HD Elite supports multiple plasma cutter configurations.

Kjellberg

• K 200: 1-3/8"
• Smart Focus 200AMP: 1-1/4"
• Smart Focus 300AMP: 1-1/2"
• Smart Focus 400AMP: 2"

Hypertherm Pierce

• MAXPRO200: 1-1/4"
• XPR170: 1-9/16"
• XPR300: 2"
• XPR460: 2-1/2"

---

Best For

• Heavy industrial manufacturing
• Large-scale fabrication
• Continuous production environments
• Large plate processing
• Multi-torch applications
• Plasma cutting
• Oxy-fuel cutting
• Industrial metal fabrication
