BT Series – Bolt Together CNC Plasma Table
BT Series – Bolt Together CNC Plasma Table
In stock
Customer-Assembled | Entry-Level Production | Cost-Effective CNC Plasma Cutting
The BT Series Bolt Together Plasma Table is a cost-effective CNC plasma cutting solution designed for beginners, entry-level production, and small fabrication shops. Supplied as a customer-assembled kit, the table features a durable bolt-together frame made from 1/8-inch and 3/16-inch material.
With a compact footprint, reliable CNC control, water-table capability, and precision cutting features, the BT Series provides an accessible way to add CNC plasma cutting capabilities to your shop.
Specifications
- Clearance Under Gantry: 8"
- Table Capacity: 0.5-inch maximum
- Rapid Travel: 400 IPM
- Positioning Accuracy: 0.008"
- Repeatability: 0.008"
- Weight: 750 lbs
- Available Sizes: 4' × 4' and 5' × 5'
Controller
- Standard FlashCut All-In-One CAD/CAM/CNC
- Windows Operating System
Features
- Neugart 10:1 planetary gearboxes
- Precision German-made helical gears
- 5-inch water bed with oversized cut area
- Ohmic sensing
- Digital torch height control
- Industrial bearings
- NEMA 24 stepper motors
- Bolt-together table design
- Adjustable feet for leveling
- Preloaded computer
- Boss Quench water table ready
Plasma Cutter Options
Hypertherm Pierce
Compatible plasma cutter options include:
- Powermax45 SYNC – 1/2"
- Powermax65 SYNC – 5/8"
- Powermax85 SYNC – 3/4"
- Powermax105 SYNC – 7/8"
- Powermax125 – 1"
Other plasma cutter options are available.
Important Information
- Customer assembly required
- This table is not compatible with accessories
- Introductory offers are subject to change
- Plasma cutter availability and configurations may vary
Ideal For
The BT Series is well suited for:
- Entry-level fabrication shops
- Small manufacturing businesses
- Welding and metalworking shops
- Custom fabrication
- CNC plasma cutting startups
- Businesses looking for an economical production cutting solution
Made in the USA.
